Item details
Creality 3D’s latest addition the Ender 3 family is the V3 SE. With a bed size of 220x220x250mm and an average printing speed of 180mm/s (250mm/s max) you can quickly print your models with great results. The machine is equipped with a CR-Touch Auto Levelling Sensor and a Strain Gauge to make levelling and Z-offset calibration a breeze. You will be up and running in no time.
In addition to these features, Creality has also added a pair of linear shafts to the Y-Axis instead of the traditional roller wheels for a more stable and longer lasting motion system. The Sprite Direct Extruder allows you to print various materials including the popular PLA, PET-G and TPU. Following on from previous models, you will also find Dual Z-Axis lead screws that are synchronised by a GT2 timing belt for more accuracy and stability.
Highlights
- Y-Axis Linear Shafts
- Dual Z-Axis Screws
- 250mm/s Print Speed
- Sprite Direct Extruder
- CR-Touch and Strain Gauge for the Perfect First Layer
Technical data
| Usable Filament Diameter | 1.75 mm |
| Max Nozzle Temperature | 260 ºC |
| Extruder Type | Direct drive |
| Recommended Printing Speed Max | 250 mm/s ( |
| Build Area | 220 mm x 220 mm x 250 mm |
| Build Plate Temp Max | 100 ºC |
| Build Plate Surface | spring steel plate |
| Build Plate Leveling System | Automatic - CRTouch |
| Build Chamber During Process | Open |
| Extruder Number Of | 1 |
| Installation Space / Requirements | |
| Total Mass Overall Dimensions | 349 mm x 364 mm x 490 mm |
| Total Weight | 7.12 kg |
| Max Power Consumption | 350 W |
| Voltage | AC: 100 V240 V (50-60 Hz) |
| Equipment | |
| Hepa Filter | No |
| Filament Runout Sensor | Yes |
| Power Loss Fail Safe | Yes |
| Touch Screen | Yes |
| Connection | |
| USB Port | No |
| WLAN | No |
| Accuracy | |
| Layer Height | 0.1 - 0.35 mm |
| Resolution | 0.1 mm |
| Shipping | |
| Shipping Box | 575 mm x 390 mm x 235 mm |
| Shipping Weight | 9.14 kg |
